SECTION 303-07C: Engine Ignition — 5.8L (4V)
| 2014 Mustang Workshop Manual
|
REMOVAL AND INSTALLATION
| Procedure revision date: 01/07/2013
|
| Item | Part Number | Description |
|---|---|---|
| 1 | W701621 | Ignition coil-on-plug cover bolt (2 required) |
| 2 | 6P067 | Ignition coil-on-plug cover |
| 3 | 14A464 | Ignition coil-on-plug electrical connector (part of 12B637) (4 required) |
| 4 | 12A366 | Ignition coil-on-plug (4 required) |
| 5 | 12405 | Spark plug (4 required) |
| Item | Part Number | Description |
|---|---|---|
| 1 | W706827 | Wire harness retainer (part of 12B637) (2 required) |
| 2 | W712595 | Ignition coil-on-plug cover stud bolt (2 required) |
| 3 | 6P068 | Ignition coil-on-plug cover |
| 4 | 12A366 | Ignition coil-on-plug (4 required) |
| 5 | 14A464 | Ignition coil-on-plug electrical connector (part of 12B637) (4 required) |
| 6 | 12405 | Spark plug (4 required) |
