MALE FEMALE

Pin #	Circuit #	Color	Gauge	Function	Qualifier	Used
1	CE612	GY-VT	18	RELAY - POWERTRAIN CONTROL MODULE		1
2	CDB08	BN	22	CONNECTOR - DIAGNOSTIC # FLASH EEPROM POWER SUPPLY (FEPS)		1
3	CBP34	VT-BN	22	FUSE - 34 OR CIRCUIT BREAKER		1
4	CCB08	VT-WH	20	SWITCH - BRAKE ON/OFF (BPP) NORMAL OPEN		1
5	CRW19	BU-OG	22	SWITCH - FRONT WIPER INTERVAL (C)		1
6	SBB22	BN-RD	16	FUSE - 22 OR CIRCUIT BREAKER		1
7						0
8	RH111	GY-BU	20	CTRL MOD. - GENERIC VREF RETURN	14290	1
8	RH111	GY-BU	22	CTRL MOD. - GENERIC VREF RETURN	14401	1
9	CMC29	GN-VT	22	SWITCH - RIDE CONTROL SWITCH SELECT		1
10	CH122	WH-OG	22	CTRL MOD. - CLIMATE # HEATER REAR WINDOW REQUEST		1
11						0
12						0
13						0
14	CH123	VT-GN	22	CTRL MOD. - BLOWER MOTOR RELAY		1
15	SBB33	RD	14	FUSE - 33 OR CIRCUIT BREAKER		1
16	CDC35	BU-WH	16	SWITCH - IGNITION # START	14401	1
16	CDC35	BU-WH	18	SWITCH - IGNITION # START	14290	1
17						0
18	VH407	YE-GN	20	SENSOR - AMBIENT TEMP.	14290	1
18	VH407	YE-GN	22	SENSOR - AMBIENT TEMP.	14401	1
19	CRW08	VT-OG	22	SWITCH - FRONT WIPER HIGH (H)		1
20	CRW17	GN-VT	22	SWITCH - FRONT WIPER INTERVAL (A)		1
21	CRW07	GY-BN	22	SWITCH - FRONT WASHER		1
22	CRW18	VT-WH	22	SWITCH - FRONT WIPER INTERVAL (B)		1
23	RE405	GN-WH	20	SWITCH - RIDE CONTROL SWITCH RETURN	14290	1
23	RMC27	WH-BN	22	SWITCH - RIDE CONTROL SWITCH RETURN	14401	1
24	VES10	WH	22	SWITCH - SPEED CONTROL COMMAND (SCCS)		1
25	CH402	YE-GN	12	RELAY - FRONT BLOWER		1
26	GD119	BK-BU	20	GROUND - ENGINE COOLING FAN BRACKET	14290	1
26	GD119	BK-BU	22	GROUND - ENGINE COOLING FAN BRACKET	14401	1
27						0
28	CBP37	WH	20	FUSE - 37 OR CIRCUIT BREAKER	14290	1
28	CBP37	WH	22	FUSE - 37 OR CIRCUIT BREAKER	14401	0
29	RES08	GN	26	CTRL MOD. - POWERTRAIN # SPEED CONTROL COMMAND RETURN (SCCSRTN)	14401	1
29	RES08	GN-BN	22	CTRL MOD. - POWERTRAIN # SPEED CONTROL COMMAND RETURN (SCCSRTN)	14290	1
30	CMC24	GY	20	SWITCH - OIL PRESSURE	14290	1
30	CMC24	GY	22	SWITCH - OIL PRESSURE	14401	1
